MH118 SERIES

MH118 SERIES Specification

Classification
Through-Bore Hollow Shaft: These encoders have a continuous central opening, allowing the encoder to be mounted directly onto a shaft, with the shaft passing entirely through the encoder's body.

Power
5, 5-30 VDC Volt (v)

Product Type
HOLLOW SHAFT

Dimension (L*W*H)
118MMX37MM Millimeter (mm)

Usage
Lifts & Elevator system. Escalator system , machine tool application specially designed for traction motor, parking systems.

Color
SILIVER

Voltage
5, 5-30VDC Volt (v)

Application
Lifts & Elevator system. Escalator system , machine tool application specially designed for traction motor, parking systems.

Material
The hollow shaft can be clamped onto the motor shaft and typically secured with a flexible tether or torque pin, allowing for minor adjustments in position and absorbing shocks and vibrations.

Connection
PUSH-PULL, LINE DRIVER, OPEN COLLECTOR

Function
Hollow shaft encoders are widely used in various industries for precise motion control, including automation, robotics, packaging machinery, and CNC machines, providing feedback on position and speed.

Size
MH118-60-1024-5-30L-5MTR

MH118 SERIES Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash on Delivery (COD)

Supply Ability
1 Piece Per Day

Delivery Time
1 Week

Packaging Details
CORRUGATED BOX

Main Domestic Market
All India

About MH118 SERIES

Design:Unlike a solid shaft, a hollow shaft has a central bore, allowing it to be mounted directly onto an existing motor or machine shaft.
Installation:This design simplifies installation as it eliminates the need for additional coupling components, which can save space and reduce complexity.
Flexibility:The hollow shaft can be clamped onto the motor shaft and typically secured with a flexible tether or torque pin, allowing for minor adjustments in position and absorbing shocks and vibrations.
Applications:Hollow shaft encoders are widely used in various industries for precise motion control, including automation, robotics, packaging machinery, and CNC machines, providing feedback on position and speed.

Robust Design for Precision Applications

The MH118 SERIES boasts a through-bore hollow shaft architecture, allowing direct and secure mounting onto motor shafts. Ideal for environments where accuracy and durability are paramount, such as lifts, elevators, and escalator systems. Its clamping and flexible tether mechanism ensures stability while absorbing shocks during operation, safeguarding reliable performance in demanding applications.

Versatile Compatibility and Output Options

With power support ranging from 5 to 30 VDC and multiple connection typesincluding PUSH-PULL, LINE DRIVER, and OPEN COLLECTORthe MH118 SERIES adapts to diverse control systems. Its design and configuration enable seamless integration into automated machinery, packaging equipment, CNC machines, and traction motors, making it a popular choice for engineers across industries.

FAQs of MH118 SERIES:

Q: How is the MH118 SERIES encoder installed on traction motors or elevator systems?

A: The encoders through-bore hollow shaft design allows it to be mounted directly onto a motor shaft, which passes completely through the encoder body. It is secured using a clamping mechanism and a flexible tether or torque pin, accommodating minor positional adjustments while minimizing the impact of vibrations.

Q: What benefits does a hollow shaft encoder offer for machine tool and parking system applications?

A: Hollow shaft encoders like the MH118 SERIES provide accurate position and speed feedback crucial for process automation. Their robust mounting method enhances durability and shock resistance, reducing maintenance needs and improving operational reliability in parking systems and machine tools.

Q: When should one use PUSH-PULL, LINE DRIVER, or OPEN COLLECTOR connection types provided by the MH118 SERIES?

A: Selection of connection type depends on the control systems requirements. PUSH-PULL is suitable for general use, LINE DRIVER provides enhanced noise immunity for longer cables, and OPEN COLLECTOR works where interfaces demand a low current switching signal. Reviewing your systems input compatibility will guide the optimal choice.

Q: Where are MH118 SERIES encoders typically employed within industrial environments?

A: These encoders are frequently used in lift and elevator systems, escalators, CNC machine tools, automation machinery, and parking systemsanywhere precise motion control and real-time feedback are essential for smooth, safe operation.

Q: What is the process for adjusting the MH118 SERIES encoder after installation?

A: Once clamped onto the motor shaft, position can be fine-tuned by adjusting the flexible tether or torque pin. This mechanism allows for minor alignment corrections, helping maintain encoder accuracy without extensive recalibration.

Q: What advantages does the siliver-colored, 118MM x 37MM dimension provide for practical usage?

A: The silver finish is corrosion-resistant, and the compact 118MM x 37MM size allows for installation in tight spaces, making it suitable for retrofit or new systems where space efficiency and durability are critical.
